Product Overview
Digital thermostatic technology provides accurate, precise and consistent temperature control in your DTV® showering system. This precision-engineered, best-in-class digital thermostatic valve is designed for use with the DTV Prompt® two-port digital interface or DTV Mode™ digital interface.Its easy plug-and-go design makes installation simple. With two independently controllable outlet ports, this valve is ideally suited for applications where only one or two shower outlets are required.
Features
- Digitally controlled thermostatic mixing valve
- Antiscald protection
- Up to 13 gpm (49.2 lpm) flow rate at 45 psi (3.1 bar) with maximum flow of 8 gpm (30.3 lpm) from one outlet
- Two independently controllable 1/2" (13 mm) outlets with copper tube connections
- 1/2" (13 mm) inlets with copper tube connections
Material
- Reinforced engineering-grade thermoplastic body
Installation
- Mounts within standard 2" x 4" (38 x 102 mm) walls
- Install valve up to 20' (6.1 meters) away from the digital interface (cable supplied with interface)
- Distance can be extended with a standard RJ-11 phone extension cord
- Prewired with three-prong plug for connection to 110 V AC receptacle
- Requires K-527, K-527-E, K-29200, K-29201, K-29202, K-29202-E, K-29204, or K-29205 bath or shower interface (sold separately)
